Description
Specification:
AC Power Supply
– 2 connectors of 4 terminals for PMG, AREP and Shunt (input & Output)
– Range: 50 to 227 VAC (115% max. during 2 mins)
– Maximum consumption: < 25VAC
DC Auxiliary Supply
– 1 connector 3 poles (input from customer power supply 8-35 VDC)
AVR Power Supply
– 1 connector 2 poles (24 VDC output to AVR)
– Maximum current 1A
Environmental
– Operating conditions: ambient temperatures from -40°C to +70°C, relative humidity less than 95%, non-condensing.
– Storage conditions: ambient temperatures from -55°C to +85°C, relative humidity less than 95%, non-condensing
– Vibration: 2 Hz to 25 Hz amplitude ±1.6 mm 25 Hz to 100 Hz acceleration ±4 g
Conformity of standard
– Safety: IEC 61010-1 (CAT III, Pol. 2)
